PEF accelerates air drying, saves energy and captures more of the natural shape, flavour, aroma and colour of the fresh produce.

  • Close-up of two slices of sweet potato on a dark surface.

  • Two dried apple slices on a dark surface.

  • Slices of dried kiwi with visible seeds on a dark surface

  • Two dried raisins close-up on a white background.

  • Two slices of dried pineapple on a dark background.

  • Close-up of a backlit tomato slice showing seeds and translucent flesh.

  • Two pieces of dried beetroot on a dark surface

PEF induces electroporation which opens cell membranes
in the treated product. This increases the internal
diffusion resulting in improved mass transfer.

  • Person in protective gear operating machinery with trays of strawberries in a processing facility.

    Save energy, increase capacity and reduce process time

    The production process becomes more sustainable with shorter process times, providing energy savings and an increase in capacity

  • Close-up of a backlit slice of citrus fruit, showing translucent flesh and seeds.

    Retain more flavour, aroma and colour

    Shorter drying times and better process control enabled by PEF mean that the raw product retains more of its original colour, shape and flavour.

  • Dried kiwi slices on dark background

    Better rehydration

    Better shape preservation with PEF treatment produces a more open product structure, enhancing rehydration.

  • Dried beetroot slices on a dark surface.

    Better shape retention

    PEF treatment produces a higher quality product with increased form stability and less shrinkage.

Discover the right Elea PEF Advantage system for your air drying line

Designed for quick and seamless integration into your existing production line, our systems are built for 24/7 operation and can withstand extreme conditions with minimal disruption.

Industrial food processing machine with Elea logo, featuring a chute and control panel.

Micro systems

  • Our latest system is targeted at smaller production lines. Based on the successful design of our Advantage B 1 system this all-in-one belt and generator slots easily into any setup.

  • The PEF Advantage B Micro provides total control over your processing capacity from 0 - 1.7 t/h.

Industrial machine with high voltage warning signs and open lid

All in one solutions

  • The compact industrial-scale PEF solution is available in two versions, the B 1 and B 1 mini. The B 1's small footprint makes integration into any production line simple.

  • The PEF Advantage B 1 Mini offers a processing capacity of 0 - 4 t/h, while the PEF Advantage B 1 handles 0 - 10 t/h.

Industrial machinery, possibly a food processing or manufacturing machine, featuring a conveyor belt and multiple access doors, with a metal frame and sturdy design.

Large-scale production

  • The largest systems in the Elea belt range deliver unmatched robustness, power efficiency, safety, and ease of use. Built with premium stainless steel and engineered to the highest standards by our German team, these systems are designed for 24/7 operation in the most demanding environments.

  • We build a range of different models for large-scale production.

    The PEF Advantage B 10-320: 0 - 15 t/h.
    The PEF Advantage B 100-550: 0 - 32 t/h.
    The PEF Advantage B 1000-850: 0 - 100 t/h.

Elea PEF Advantage benefits for air drying

  • Two dried beetroot slices on a dark surface.

    Better shape retention

  • Close-up of two dried sweet potato slices on a dark surface.

    Better colour

  • Close-up of a tomato slice with visible seeds and segments, backlit to highlight translucent texture.

    Better flavour & aroma

L*a*b* value

L*a*b* Colour difference for air-dried sweet potato

Retain a brighter and more intense colour with PEF.

Moisture content [%]

- 40 %

←

time [min]

40 % shorter drying of air-dried tomatoes

In this example, tomato slices were dried at 50°C. A noticeable difference in moisture content over time was observed, demonstrating a 40 % shorter drying time after PEF treatment.

Moisture content [%]

time [min]

Yellow onions dry faster, gentler, with fewer quality losses

PEF treated yellow onions dried at 75°C have nearly the same drying time compared to an untreated sample dried at 85°C!

Moisture content [%]

time [min]

Rehydration rate of yellow onions doubled with PEF

The open cell structure caused by PEF improves rehydration. In this example the final water uptake for the PEF-treated sample is with 66.8 % nearly twice as high as for the untreated sample with 35.1 %.

Discover how PEF can reduce food waste and enable new product opportunities

PEF can enable new dried product opportunities for producers looking to make better use of their surplus or second-class produce.

PEF solutions, customer care and support

Apple processing machine with green apples being processed inside, located in an industrial setting.

Built for you

Each of our systems is customisable to your requirements. From your initial brief to final installation, we quickly get your new PEF system working perfectly for your product.

Two men in a laboratory setting, one in a lab coat with "elea" logo, both focused on a task.

Application support

Our experts can work with you to test the effectiveness of our PEF systems for your requirement, either in-house at our specially designed PEF pilot hall or on-site at your production line.

Two workers in lab coats and safety hats stand next to industrial machinery with control panels and caution signs in a factory setting.

Technical care & support

We offer a full 24-hour support service worldwide. Our specialist installation and training teams work closely with our clients to ensure our systems' smooth, swift, and successful commissioning.
